Delta-Q is a durable and economical precision flow regulator modules that can be used in conjunction with other Smartflow components such as:
The Delta-Q Regulator allows full adjustability of flow volume from unrestricted flow to complete shut off using the manual flow control knob.
The modular design allows users to customize models meeting Scientific Cooling requirements for each application. The glass-filled nylon body is lightweight and durable. Internal stainless steel components are resistant to corrosion.
End Caps – Brass or Glass Filled Nylon
Regulator Body – Glass-Filled Nylon
Flow Body – Polysulfone
Indicator Ring – Silicone Rubber
Piston – Acetal
Spring – Stainless Steel
O-Rings – EPDM
Gauge Block – Brass
Optional Quick-Connect Fittings – Brass
Flow Range – 0.25 – 2 gpm, 1-8 lpm
Accuracy – +10% full scale
Operating Temperature Max – 210°F (99°C)
Operating Pressure Max – 100 psi (6.9 bar)
Dial Thermometer – 0°F to 250°F (-20° to 120°C), +2% accuracy (full scale)
| FC3 | B | E | Q | |
|---|---|---|---|---|
| Brass End Caps | ||||
| 1/4″ NPT(F) | FC2 | |||
| 1/4″ BSPP(F) | FC2B | |||
| 3/8″ NPT(F) | FC3 | |||
| 3/8″ BSPP(F) | FC3B | |||
| Nylon End Caps | ||||
| 1/4″ NPT(F) | FCP2 | |||
| 1/4″ BSPP(F) | FCP2B | E | English (temp in F and flow in GPM) | |
| 3/8″ NPT(F) | FCP3 | |||
| 3/8″ BSPP(F) | FCP3B | M | Metric (temp in C and flow in LPM) | |
| Accessories | ||||
| thermometer (standard) | B | |||
| thermometer with quick connect socket and plug | E |
Dr. Eddy is calibrated for use with water only. A 10% glycol scale is available on request. The addition of glycol to cooling water can have a dramatic effect on Turbulent Flow, increasing the flow rate needed to achieve optimum cooling efficiency.
